Macro Reference
445
8
Appendices
Vision System FH/FZ5 Series
User’s Manual (Z340)
Example
Copies the measurement region figure of the Shape Search III processing unit of Processing Unit number 2
in the measurement flow of scene 0 to the measurement region of the Shape Search III processing unit of
Processing Unit number 5. The measurement region figure of the Shape Search III processing item is figure
1.
Useable Modules
Scene Control Macro / Communication Command Macro / Unit Macro
Supported Versions
Version 3.50 or later
Related Items
Rem Copy the figure of the measurement region
CopyUnitFigure 0, 2, 1, 5, 1
GetUnitFigure (Reference: X Details (p.554)) MeasureStart (Reference: X Details (p.617))
MeasureStop (Reference: X Details (p.619)) SceneNo (Reference: X Details (p.691))
SetUnitFigure (Reference: X Details (p.733)) UnitNo (Reference: X Details (p.790))
Ut (Reference: X Details (p.793))
