Technical Characteristics
192-120100 N16 C3I10T10 - December 2010
221
Ballast resistors for Compax3
Ballast resistor (see on page
187)
Device
Rated output
BRM08/01 (100Ω)
Compax3S025V2
Compax3S015V4
Compax3S038V4
60 W
BRM05/01 (56
Ω
)
Compax3S063V2
Compax3S075V4
180 W
BRM05/02 (56Ω)
Compax3S075V4 570 W
BRM10/01 (47
Ω
)
Compax3S150V4 570 W
BRM10/02 (470
Ω
)
Compax3S150V4 1500 kW
BRM04/01 (15
Ω
)
Compax3S150V2
Compax3S300V4
PSUP20D6
570 W
BRM04/02 (15
Ω
)
Compax3S150V2
Compax3S300V4
PSUP20D6
740 W
BRM04/03 (15Ω)
Compax3S300V4
PSUP20D6
1500 W
BRM09/01 (22
Ω
)
Compax3S100V2 570 W
BRM11/01 (27
Ω
)
Compax3H0xxV4 3500 W
BRM13/01 (30
Ω
)
PSUP10D6
PSUP20D6**
500 W
BRM14/01 (15Ω)
PSUP10D6*
PSUP20D6
500 W
BRM12/01 (18
Ω
)
Compax3H1xxV4 4500 W
*for PSUP10D6 2x15Ω in series
**for PSUP20D6 2x30Ω parallel
