Technical Characteristics
C3I10T10
222
192-120100 N16 C3I10T10 - December 2010
Size / weight Compax3S
Controller type
Dimensions
HxWxD [mm]
Weight [kg]
Compax3S025V2
191 x 84 x 172 2.0
Compax3S063V2
191 x 100 x 172 2.5
Compax3S015V4
248 x 84 x 172 3.1
Compax3S100V2
248 x 115 x 172 4.3
Compax3S150V2
248 x 158 x 172 6.8
Compax3S038V4
248 x 100 x 172 3.5
Compax3S075V4
248 x 115 x 172 4.3
Compax3S150V4
248 x 158 x 172 6.8
Compax3S300V4
380 x 175 x 172 10.9
Minimum mounting distance: 15mm at the sides, above & below 100mm
Protection type IP20
Drawings, Mounting (see on page 67, see on page 73)
Size / weight PSUP/Compax3M
Device type
Dimensions HxWxD
[mm]
Weight
[kg]
PSUP10D6
360 x 50 x 263 3.95
PSUP20D6 & PSUP30D6
360 x 100 x 263 6.3
Compax3M050D6
360 x 50 x 263 3.5
Compax3M100D6
360 x 50 x 263 3.6
Compax3M150D6
360 x 50 x 263 3.6
Compax3M300D6
360 x 100 x 263 5.25
Protection type IP20
Size / weight Compax3H
Mounting (see on page 67, see on page 73)
Controller type
Dimensions
HxWxD [mm]
Weight [kg]
Compax3H050V4
453 x 252 x 245 17.4
Compax3H090V4
668.6 x 257 x 312 32.5
Compax3H125V4
720 x 257 x 355 41
Compax3H155V4
720 x 257 x 355 41
Protection class IP20 when mounted in a control cabinet (not for
Compax3H1xxxV4)
Mounting

Parker Compax3 I10T10 Specifications

General

Rated Current	10 A
Protection Class	IP20
Supply Voltage	200-480 VAC
Control Interface	EtherCAT, CANopen
Feedback Options	Resolver
