Printing
QL-300 User Guide 115
b) Check the gap sensor position
Align the paper, and check the actual position of the label and the gap sensor
position.
If the position of the label and the gap sensor position do not align, rotate the
Sensor Position Adjustment Dial to adjust the position (go to step 8).
The gap sensor position is set, at the factory, to 65 mm from the right edge of the
label liner.
Adjust the position of the arrow so it is in the center of the labels of the media you
are using.
8 Rotate the Sensor Position Adjustment Dial to adjust the sensor position.
• If you rotate the Sensor Position Adjustment Dial in direction A, the sensor position
moves in the direction C.
• If you rotate the Sensor Position Adjustment Dial in direction B, the sensor position
moves in the direction D.
