QuickLabel Systems QL-300

To Next Page

To Previous Page

Troubleshooting

QL-300 User Guide 261

7 Remove the print cartridge set.

8 Place the removed print cartridge set on a flat surface covered with newspaper or

something similar, and cover it with paper so it is not exposed to direct light.
