9. Make four holes in the scanner left cover with a screwdriver as shown [A].
• Smooth the four holes in the scanner left cover as shown [B].
10. Route the USB cable [A] through the gaps in the left scanner cover.
11. Secure the USB2.0/SD Slot [B] with the left scanner cover as shown above ( x 4: M3x8).
• Use the screw holes [C] as shown above.
2. Installation
108
