Ricoh MPC 2800 AT-C2 User Manual

Jam Code SP Display Description
LCD
Display
7504 11 Vertical Transport 1: ON
Vertical transport sensor 1 does not detect
paper from tray 1.
A
7504 12 Vertical Transport 2: ON
Vertical transport sensor 2 does not detect
paper from tray 2.
A
7504 13 Bank Transport 1
Vertical transport sensor 1 or relay sensor does
not detect paper from tray 3 (LCT).
Y
7504 15 - - -
7504 16 - - -
7504 17 Registration: ON Registration sensor does not detect paper. B
7504 18 Fusing Entrance: ON Fusing entrance sensor does not detect paper. B
7504 19 Fusing Exit: ON Fusing exit sensor does not detect paper. B
7504 20 Paper Exit: ON Paper exit sensor does not detect paper. C
7504 21 Relay Exit: ON
Tray exit sensor (bridge unit) does not detect
paper.
D
7504 22 Relay Transport: ON
Relay sensor (bridge unit) does not detect
paper.
D
7504 23 - - -
7504 24 Junction Gate Feed: ON Junction gate jam sensor does not detect paper. C
7504 25 Duplex Exit: ON Duplex exit sensor does not detect paper. Z
7504 26 Duplex Entrance: ON (In) Duplex entrance sensor does not detect paper. Z
7504 27
Duplex Entrance: ON
(Out)
Duplex entrance sensor does not detect paper
again after paper has passed this sensor.
Z
7504 28 - - -
7504 51 SEF Sensor 1 Vertical transport sensor 1 does not turn off. A
7504 52 SEF Sensor 2 Vertical transport sensor 2 does not turn off. A
7504 53 Bank SEF Sensor 1
Vertical transport sensor or relay sensor 1 does
not turn off.
Y
