Fuse
Rating
Symptom when turning on the main switch
115V 220V - 240V
FU7 10A/125V 10A/125V 24VS power to the IOB not supplied.
FU8 10A/125V 10A/125V 24VS power to the IOB not supplied.
FU9 6.3A/125V 6.3A/125V 24V power to the IOB not supplied.
FU10 6.3A/125V 6.3A/125V 24V power to the SIO not supplied.
FU11 6.3A/125V 6.3A/125V 24V power to the BICU and MB not supplied.
FU12 6.3A/125V 6.3A/125V 24V power to the PFU or LCT not supplied.
FU13 6.3A/125V 6.3A/125V 24V power to the finisher not supplied.
FU14 5A/250V 5A/250V 5V power to the BICU not supplied.
IH Inverter
Fuse
Rating
Symptom when turning on the main switch
115V 220V - 240V
FU1 15A/125V 8A/250V
15V power to the IH coil unit is not supplied.
SC689 occurs.
FU2 115°C No response
FU3 115°C No response
FU4 1A/250V
15V power to the IH coil unit is not supplied.
SC689 occurs.
• For continued protection against risk of fire, replace only with same type and rating of fuse.
