006
Stand-by: Threshold: Upper
Limit
*ENG [0 to 200 / 180 / 1 deg/step]
Specifies the threshold temperature of the pressure roller between M (middle) and H (high).
This SP is referred when the input voltage of the IH inverter is 93% or less (adjustable with
SP1-916-026).
007
Stand-by: Threshold: Lower
Limit
*ENG [0 to 200 / 120 / 1 deg/step]
Specifies the threshold temperature of the pressure roller between L (low) and M (middle).
This SP is referred when the input voltage of the IH inverter is 93% or less (adjustable with
SP1-916-026).
008
Mid. Thick: A3: Threshold:
Upper Limit
*ENG [0 to 200 / 200 / 1 deg/step]
Specifies the threshold temperature of the pressure roller between M (middle) and H (high).
This SP is referred when the paper of 275 mm width or more is used in the middle thick paper
and 205/154 mm/sec line speed mode.
009
Mid. Thick: A3: Threshold:
Lower Limit
*ENG [0 to 200 / 190 / 1 deg/step]
Specifies the threshold temperature of the pressure roller between L (low) and M (middle).
This SP is referred when the paper of 275 mm width or more is used in the middle thick paper
and 205/154 mm/sec line speed mode.
9912 [Target Angle] Ferrite Roller Paper Size Adjustment DFU
001 A3/DLT *ENG [0 to 960 / 323 / 1 PULSE/step]
002 B4 *ENG [0 to 960 / 381 / 1 PULSE/step]
003 A4/LT *ENG [0 to 960 / 400 / 1 PULSE/step]
004 B5 *ENG [0 to 960 / 498 / 1 PULSE/step]
005 A5/HLT *ENG [0 to 960 / 525 / 1 PULSE/step]
006 B6 *ENG [0 to 960 / 525 / 1 PULSE/step]
007 A6 *ENG [0 to 960 / 525 / 1 PULSE/step]
9921 Page Correction Setting *CTL
Not used in this machine.
[0 to 9999999/ 0 / 1]
System Service Mode
461
8
