*1: The machine detects either 11" x 17" SEF or A3 SEF, depending on the setting of SP 5-181-003.
*2: The machine detects either 8.5" x 14" SEF or B4 SEF, depending on the setting of SP 5-181-004.
*3: The machine detects either 11" x 81/2" LEF or A4 LEF, depending on the setting of SP 5-181-002.
*4: The machine detects either B5 LEF or 10.5" x 7.25" LEF, depending on the setting of SP 5-181-005.
Table 3: Paper Size (By-pass Table)
0: ON, 1: OFF
By-pass Paper Size Sensor
Length Sensor NA EU/ASIA
bit3 Bit2 Bit1 Bit0
1 1 1 1 1 HLT SEF A6 SEF
0 1 1 1 1 HLT SEF A6 SEF
0 0 1 1 1 HLT SEF A5 SEF
1 0 1 1 1 HLT SEF A5 SEF
1 0 0 1 0 LT/LG SEF*
1
A4 SEF
1 0 0 1 1 LT/LG SEF*
1
A5 LEF
1 1 0 1 0 LT/LG SEF*
1
A4 SEF
1 1 0 1 1 LT/LG SEF*
1
A5 LEF
1 1 0 0 0 DLT SEF A3 SEF
1 1 0 0 1 LT LEF A4 LEF
1 1 1 0 0 DLT SEF A3 SEF
1 1 1 0 1 LT LEF A4 LEF
*1: The paper size (LT or LG) can be selected with SP1-007-001.
Table 4: APS Original Size Detection
Original Size Length Sensor Width Sensor
SP4-301
display
Metric version Inch version L3 L2 L1 W1 W2
8. Appendix: SP Mode Tables
474
