6160 12 Bank: Palau: Slide Switch Closed Open
Table 1: Paper Height Sensor
0: Deactivated, 1: Activated (actuator inside sensor)
Remaining paper Paper height sensor 1 Paper height sensor 2
Full 0 0
Nearly full 1 0
Near end 1 1
Almost empty 0 1
Table 2: Paper Size Switch (Tray 2)
Switch 1 is used for tray set detection.
0: Pushed, 1: Not pushed
Models Switch Location
North America Europe/Asia 4 3 2
11" x 17" SEF*
1
(A3 SEF)
A3 SEF*
1
(11" x 17" SEF)
0 0 1
8.5" x 14" SEF
*2
(B4 SEF)
B4 SEF
*2
(8.5" x 14" SEF)
0 0 0
A4 SEF A4 SEF 1 1 0
8.5" x 11" SEF 8.5" x 11" SEF 1 1 1
B5 SEF B5 SEF 0 1 1
11" x 81/2" LEF*
3
(A4 LEF)
A4 LEF*
3
(11" x 81/2" LEF)
1 0 0
10.5" x 7.25" LEF*
4
(B5 LEF)
B5 LEF*
4
(10.5" x 7.25" LEF)
0 1 0
A5 LEF A5 LEF 1 0 1
System Service Mode
473
