SCM CU 300C - Tenoning Hood-Fence Unit

4 - INSTALLATION
EN
Pag. 38/53 - Cap. 4 THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
4.3.73.4 TENONING HOOD-FENCE UNIT
(cu_4-3-73-4_0.0)
- Rest the hood on the table in the position proper for the milling depth required, the fasten it by tightening
knobs (1 fig. 4.3-73-4).
Fig. 4.3-73-4
