SCM CU 300C - Technical data

3 - TECHNICAL SPECIFICATIONS
EN
Pag. 6/22 - Cap. 3 THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
3.2 TECHNICAL DATA
(ev_3-2_0.0)
SAW
GENERAL SPECIFICATIONS
Fixed table dimensions 1115 x 335 mm
Slide dimensions With “Slide 1600” 1600 x 270 mm
Slide dimensions With “Slide 2250” 2250 x 270 mm
Slide dimensions With “Slide 2600” 2600 x 270 mm
Blade inclination from 90° to 45°
50 Hz Øi 30 x 315 mm
Saw blade maximum diameter
60 Hz Øi 15.9 x 315 mm
50 Hz Øi 30 x 250 mm
Saw blade minimum diameter
60 Hz Øi 15.9 x 250 mm
Scoring saw blade diameter Øi 20 x 80 mm
Maximum projection at 90° With a blade of 315 mm 100 mm
Maximum projection at 45° With a blade of 315 mm 78 mm
Maximum projection at 90° With a blade of 300 mm 92,5 mm
Maximum projection at 45° With a blade of 300 mm 73 mm
Maximum projection at 90° With a blade of 250 mm 68 mm
Maximum projection at 45° With a blade of 250 mm 55 mm
Saw blade rotation speed ( 50 Hz - 60 Hz ) 3500 r.p.m.
Saw blade stop time : less than 10 seconds
Scoring saw blade rotation speed ( 50 Hz - 60 Hz ) 8000 r.p.m.
Motors:
50 Hz 5,0 kW
Saw motor power:
60 Hz 6,0 kW
Technical details: see data plate on the motor
Duty cycle: S6 - 40%
Conditions of service: see Par. 1.10
Net weight: see plate of machine identification
Working voltage and frequency: see plate of machine identification
