9a - OPERATIONS AND ADJUSTMENTS OF SPINDLE
EN
Pag. 14/45 - Cap. 9a THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
9A.8.1 TENONING
(cu_9a-8-1_0.0)
- Fit the tenoning hood and set it as described in paragraph 9.44.
- To move the rule loosen the knobs (M fig. 9.8-1).
- Position the telescopic ruler in such a way that the pin (E fig. 9.8-1) fits into place against the device (S fig.
9.8-1).
- Tighten the knobs (M fig. 9.8-1).
- Rest the workpiece against rule (G fig. 9.8-1), so that its projection to the tool is larger than the tenoning
depth.
DANGER-WARNING:
make sure that no contact between tenoning table and tool is possible.
- Clamp the workpiece with the presser foot (P fig. 9.8-1) by lowering the lever (D fig. 9.8-1).
9A.8.1.1 CLAMPING ARM USE
(cu_9a-8-1-1_0.0)
- For height adjusting loosen handle (C fig. 9.8-1).
- By means of lever (D fig. 9.8-1) lower foot (P fig. 9.8-1) to clamp the piece.
DANGER-WARNING:
always lock the piece using the presser provided.
