SCM CU 300C - Manual fence for parallel cuts

7 - SUPPORTING FRAME AND FENCE FOR PARALLEL CUTS: USE AND
ADJUSTMENT
EN
Pag. 4/26 - Cap. 7 THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
7.14 MANUAL FENCE FOR PARALLEL CUTS
(gu_7-14_0.0)
7.14.1 SETTING TO ZERO THE FENCE FOR PARALLEL CUTS
(gu_7-14-1_0.0)
1) With motors off lift the saw guard.
2) Unlock the fence for parallel cuts (D fig. 7.14-1) by means of handle (L fig. 7.14-1) and move it in order to
read a value (e.g. X=200 mm) between the edge (R fig. 7.14-1) turned to the blade and millimeter rule (N fig.
7.14-1).
3) Measure the distance between saw blade and parallel fence.
4) If necessary, adjust the position by loosening the fastening screws (A fig. 7.14-1) and repositioning the
tubular section (P fig. 7.14-1) in order to read the same value previously measured on the edge (R fig. 7.14-
1) of fence.
5) Lock the fence unit with handle (L fig. 7.14-1).
Lower the guard and carry out a test cut.
