SCM CU 300C - Saw blade tilting

6 - SAW UNIT USE AND ADJUSTMENT
EN
Pag. 4/11 - Cap. 6 THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
6.3 AXIS POSITIONING
(gu_6-3_0.0)
6.3.1 HEIGHT ADJUSTING OF THE SAW UNIT
(ev_6-3-1_0.0)
- Fit the handwheel (E fig. 6.3-1) on the pin (F fig. 6.3-1) and turn it to adjust the height of the saw assembly.
NOTE-INFORMATION:
the saw blade height is right when it exceeds the piece thickness by 1-1.5 cm.
FORBIDDEN:
with protective hood fixed to the riving knife, it's strictly forbidden to carry out not-through cuts.
FORBIDDEN:
with
"DADO SET" (U.S.A. and CANADA version).
Lowering the "dado set" blades beyond the limit (W fig. 6.3-1) indicated on the warning sticker IS
FORBIDDEN.
6.3.2 SAW BLADE TILTING
(ev_6-3-2_0.0)
FORBIDDEN:
with
"DADO SET" (U.S.A. and CANADA version).
IT'S FORBIDDEN tilting saw unit when using "dado blade".
CAUTION:
when inclining the saw blade from 90° to 45°, first lower the engraving blade to prevent interference
with the wagon and saw table.
- Fit the handwheel (E fig. 6.3-1) on the pin (H fig. 6.3-1).
- Loosen the knob (G fig. 6.3-1) and turn the handwheel to adjust the inclination of the saw-engraver
assembly.
- Read the inclination value of the saw blade on the index (L fig. 6.3-1).
