SCM CU 300C - Surfacing Pieces of Square Section

10 - USE AND ADJUSTMENT OF PLANER SPINDLE GUARD AND SAFE WORKING
EN
Pag. 12/20 - Cap. 10 THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
10.3.1.4 SURFACING PIECES OF SQUARE SECTION
(fs_10-3-1-4_0.0)
and bridge-type protection
NOTE-INFORMATION:
adjust the bridge guard as described in the previous sections.
- the bridge guard must rest on the workpiece (fig. 10.3-1-4) and against the fence.
- Move the piece forwards by keeping the fingers bended.
Fig. 10.3-1-4
