10 - USE AND ADJUSTMENT OF PLANER SPINDLE GUARD AND SAFE WORKING
THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN Cap. 10 Pag. 13/20
10.3.1.5 SURFACING SHORT PIECES
(fs_10-3-1-5_0.0)
and bridge-type protection
NOTE-INFORMATION:
adjust the bridge guard as described in the previous sections.
- Press the guard bridge on the piece by keeping the hand flat and move the piece forwards with the right
hand by using a pusher.
- Rest the left hand on the guard bridge and as soon as the piece rests on the outlet table.
- The pusher shall be thinner than the workpiece.
Fig. 10.3-1-5
