20.28 MAKING THE PARTS WHICH GET WORN
(ev_20-28_0.0)
20.28.1 REPLACING THE CHIP BREAKER
(ev_20-28-1_0.0)
Rule for 90°-cuts
If you have to replace wood part (M fig. 20.28-1), request it:
- to SCM dealer;
- or to SCM Spare Parts Department,
or make it by using beech; figure 20.28-1 indicates the measures.
Rule for tenoning table and guard
If you have to replace wood part (K fig. 20.28.1), request it:
- to SCM dealer;
- or to SCM Spare Parts Department,
or make it by using beech; figure 20.28.1
indicates the measures.
To replace the worn splinter guard, use the screws (X fig. 20.28.1).
Reassemble the new splinter guard and tighten the screws (X).
