SCM CU 300C - Start up - Stop from Feeder

- FEEDER SPECIFICATIONS
EN
Pag. 2/3 - Cap. THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
APPENDIX - A
(appendice - a)
A-1 FEEDER SPECIFICATIONS
(a-trasc_a-1)
FEEDER NOT SUPPLIED BY SCM
NOTE-INFORMATION:
connect the feeder to the relative socket (A fig. A.1 max. power 0.55 kW) .
The feeder must have the following specifications.
- The feeder instructions manual must indicate that it can be fitted on SPINDLE MOULDER, SAW, SURFACE
PLANING
- Max weight: 50 kg
- Max power: 0.55 kW
A-2 START UP - STOP FROM FEEDER
(a-trasc_a-2)
DANGER-WARNING:
when there is a feeder emergency stop press pushbutton (N fig. A.1).
DANGER-WARNING:
to connect the feeder (not supplied by SCM ), use only the socket (A fig. A.1 power max. 0,55 kW),
because when the emergency pushbutton is pressed, the power supply to the socket (A) is also
interrupted, thus blocking the feeder.
FORBIDDEN:
the electrical setup of the feeder (A fig. A.1) must be used exclusively to supply the feeder.
Any other use is FORBIDDEN.
NOTE-INFORMATION:
the feeder can be started when the spindle moulder motor has reached the right number of rpm.
