8 - USE AND ADJUSTMENT OF MORTISER
THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN Cap. 8 Pag. 9/11
8.3.1 SLOT DEPTH LIMITATION
(fs_8-3-1_0.0)
In the case of dead holes you have to adjust the stroke of additional table (A fig. 8.3-1) (axis Z):
- try the forward stroke using lever (F fig. 8.3-1) and lock the depth stop by tightening lever (H fig. 8.3-1).
Fig. 8.3-1
