9a - OPERATIONS AND ADJUSTMENTS OF SPINDLE
EN
Pag. 16/45 - Cap. 9a THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
9A.8.2 OBLIQUE TENONS
(cu_9a-8-2_0.0)
The working of oblique tenons is quick, because it is sufficient to turn telescopic rest rule (G fig. 9.8-2) clockwise.
- Loosen the knobs (F fig. 9.8-2).
- Turn the rule to the desired angle clockwise (+ / index 1) then read the value directly on scale (T fig. 9.8-2)
applied on the table.
- Tighten the knobs (F fig. 9.8-2).
To move the rule (G fig. 9.8-2) loosen the knobs (F fig. 9.8-2).
This adjustment may be needed to suit the various cutter diameters.
9A.8.2.1 CLAMPING ARM USE
(cu_9a-8-2-1_0.0)
- For height adjusting loosen handle (C fig. 9.8-2).
- By means of lever (D fig. 9.8-2) lower foot (P fig. 9.8-2) to clamp the piece.
DANGER-WARNING:
always lock the piece using the presser provided.
