SCM CU 300C - Adjusting Standard Indicator

9 - THICKNESSING USE AND ADJUSTING
EN
Pag. 8/12 - Cap. 9 THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
9.5.1 ADJUSTING STANDARD INDICATOR
(fs_9-5-1_0.0)
If the indicator (L fig. 9.5-1) gives an imprecise indication, restore adjustments as follows:
- unscrew screw (A fig. 9.5-1) and remove indicator.
- Manually rotate indicator until the pointer, which is always in a vertical position, does not coincide with 0°
notch.
Fig. 9.5-1
