SCM CU 300C - Surfacing Workpieces of Thickness Less 75 MM

10 - USE AND ADJUSTMENT OF PLANER SPINDLE GUARD AND SAFE WORKING
EN
Pag. 6/20 - Cap. 10 THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
10.3.1.1 SURFACING WORKPIECES OF THICKNESS LESS 75 MM
(fs_10-3-1-1_0.0)
and bridge-type protection
- Loosen knob (C fig.10.3-1-1) and rest bridge (A fig.10.3-1-1) against fence (G fig. 10.3-1-1); lift bridge (A
fig.10.3-1-1) by means of knob (B fig.10.3-1-1) at the height equal to the workpiece thickness.
- Rest the workpiece against the fence and move it forwards with the right hand in order to fit it under the
bridge (1 fig.10.3-1-1).
- Push the workpiece forwards(from the inlet table side)(2 fig.10.3-1-1) by keeping the hands flat on the
workpiece, let one hand and then the other hand climb over the guard bridge.
- As soon as possible press both hands on the workpiece on the outlet table side to continue the workpiece
feed (3 fig.10.3-1-1).
