9.1 PRELIMINARY ADJUSTMENT FOR PASSING FROM
PLANING TO THICKNESSING
(fs_9-1-0.0)
NOTE-INFORMATION:
THICKNESSING
This operation is carried out for obtaining the required thickness of a given workpiece after
surfacing.
9.1.1 MACHINE WITH MANUAL TABLE LIFTING
(fs_9-1-1_0.0)
DANGER-WARNING
remove the planing fence unit (A fig. 9.1-1) from the table.
- Stop cutterblock motor.
- Wait for a few seconds until the cutterblock stops completely.
- Slacken the levers (B fig. 9.1-1) as shown in figure.
Llift the planing tables (C, D fig. 9.1-1) by using the handles (G fig. 9.1-1);
(the opening of the tables activates a microswitch that stops the machine from switching on USA
and CANADA).
CAUTION:
check that the block (N fig. 9.1-1) of the table opening is correctly positioned.
- Turn the chip conveyor hood (F fig. 9.1-1) upside down securing it by the spring (M fig. 9.1-1) in the
protection (E fig. 9.1-1); the rotation of the protection guard reacts again on the micro-switch, reactivating the
machine (USA and CANADA).
NOTE-INFORMATION:
thicknessing can only be carried out if the safety guard (F fig. 9.1-1) is in position.
(U.S.A. and CANADA version): this position is checked by an electro-mechanical limit switch.
