5 - CONTROLS
EN
Pag. 12/14 - Cap. 5 THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
5.5.1 MACHINE WITH COUNTERCLOCKWISE SPINDLE
ROTATION (AGAINST FEED DIRECTION)
(cu_5-5-1_0.0)
NOTE-INFORMATION:
when possible always use this rotation direction when possible as it is the normal rotation
direction.
Machine Start procedure
- Turn the magnetothermal switch (A fig. 5.5-2) to position I.
Move main switch (1 fig. 5.5-2) to position I (U.S.A. and CANADA).
1) Turn the selector switch (N fig. 5.5-2) towards the left and keep it in that position.
2) Press the button (M fig. 5.5-2) to start the operator unit; release the selector switch (N fig. 5.5-2) to return to
the central position.
3) Go to the relative work station.
NOTE-INFORMATION:
when you stop the machine it is not necessary repeat instructions 1 if you want to start with
counterclockwise spindle rotation.
Machine Stop procedure
- Press the (M fig. 5.5-2) button.
- Set the selector of the magnetothermal switch (A fig. 5.5-2) to position "0".
- Move the selector switch (C fig. 5.5-2) to position "0".
FORBIDDEN:
(U.S.A. and CANADA) it is forbidden to stop the moulder motor by turning selector (C fig. 5.5-2) to
; unlocked motor brake, pilot lamp switched on.
5.5.2 MACHINE WITH CLOCKWISE ROTATION (FEED
DIRECTION)
(cu_5-5-2_0.0)
DANGER-WARNING:
for safety reasons rotation inversion cannot be used when tenoning.
DANGER-WARNING:
avoid this direction of rotation as much as possible: as the cutter rotates "in feed direction "there
is the risk that the cutter withdraws the workpiece from the presser: pay attention!.Set the pressers
(see Chapter 9A).
