4 - INSTALLATION
EN
Pag. 8/53 - Cap. 4 THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
4.3 FITTING THE PARTS DEMOUNTED FOR TRANSPORT
REASONS
(ev_4-3_0.0)
For packing and transport reasons some machine members are removed.
4.3.A DISPLACING WHEELS - ASSEMBLY
(cu_4-3-a_0.0)
The unit is composed by:
- 2 fixed wheels (A fig. 4.3-A).
- 1 movement lever (B fig. 4.3-A).
1) Use lever (B fig. 4.3-A) to lift machine base slightly;
2) engage head of screw on fixed wheel (A fig. 4.3-A) in base feet hole as indicated in the figure;
3) move lever (B fig. 4.3-A) from opposite side of machine, insert lever in relative attachment (it is indicated
with the arrow F) and move the machine.
DANGER-WARNING:
at the end of the operation, disassemble the moving wheels (A fig. 4.3-A) and fix the machine to the
ground (see Par. 4.2);
the machine must be fixed to the floor.
