SCM CU 300C - Dimensions of workpiece to be thicknessed

3 - TECHNICAL SPECIFICATIONS
EN
Pag. 2/22 - Cap. 3 THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
3.1 DIMENSIONS OF WORKPIECE TO BE THICKNESSED
(ev_3-1_0.0)
SAW
DIMENSIONS OF WORKPIECE TO BE MILLED
Maximum cutting height at 90° With a blade of Ø 315 90 mm
Maximum cutting height at 45° With a blade of Ø 315 63 mm
Maximum cutting height at 90° With a blade of Ø 300 82,5 mm
Maximum cutting height at 45° With a blade of Ø 300 57 mm
Maximum cutting height at 90° With a blade of Ø 250 62 mm
Maximum cutting height at 45° With a blade of Ø 250 40 mm
WITH – DADO SET (USA AND CANADA VERSION)
Maximum cutting height at 90° With a blade of Ø 315 70 mm
Maximum cutting height at 45° With a blade of Ø 315 49 mm
Maximum cutting height at 90° With a blade of Ø 300 63 mm
Maximum cutting height at 45° With a blade of Ø 300 43,5 mm
Maximum cutting height at 90° With a blade of Ø 250 38 mm
Maximum cutting height at 45° With a blade of Ø 250 26 mm
Maximum cutting height at 90° With DADO SET blade of Ø 8” 23 mm
Maximum length When squared with “slide 1600” 1600 mm
Maximum length
When squared with “slide 2250” 2250 mm
Maximum length
When squared with “slide 2600” 2600 mm
Maximum width – CU 300C
For cutting to the parallel guide 815 mm
Maximum width – CU 410C
For cutting to the parallel guide 900 mm
