SCM CU 300C - Electric Connection; Check the Correct Connection

4 - INSTALLATION
EN
Pag. 50/53 - Cap. 4 THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
4.4.2 ELECTRIC CONNECTION
(st-el_4-4-2_0.0)
DANGER-WARNING:
before performing the connection disconnect the main line switch; in any case check that the
electrical cable used for the machine connection is not live.
Connect the machine to the elecric system by proceeding as follows:
- prearrange the feeding cable near the terminal board (A fig. 4.4);
- connect the cables to the terminals L1-L2-L3 of the socket and the earthing cable to the terminal marked by the
symbol (
/ PE );
- connect socket (A fig. 4.4) to plug (B fig. 4.4).
Version U.S.A.-CANADA
- shut off the power (indicate it by a sign);
- take off the cover of the terminal board (C fig. 4.4);
- insert the supply cable into proper terminal screw (P fig. 4.4);
- connect the 3 phases to terminals L1-L2-L3 (fig. 4.4);
- connect the ground cable yellow-green, to terminal (
/ PE );
- if necessary connect neutral cable to terminal (N fig. 4.4);
- fit the cover of terminal board C;
- clamp terminal screw (P fig. 4.4).
4.4.3 CHECK THE CORRECT CONNECTION
(st-el_4-4-3_0.0)
DANGER-WARNING:
CAREFUL WITH THE ELECTRICAL CONNECTION.
Incorrect rotation of the tool causes danger to the operator and damage to the product. Start the
machine for a fraction of a second and check that the saw blade turns clockwise. Should rotation
be incorrect, immediately switch off the power and invert two of the three phases on the terminals
(L1-L2-L3).
NOTE-INFORMATION:
the documentation with wiring diagram is inside the accessory suitcase.
