SCM CU 300C - Adjustments; 1.1 Spindle Height Adjusting

9a - OPERATIONS AND ADJUSTMENTS OF SPINDLE
EN
Pag. 4/45 - Cap. 9a THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
9A.1 ADJUSTMENTS
(cu_9a-1_0.0)
DANGER-WARNING:
ensure that during shaft movement there is no interference with machine parts.
9A.1.1 SPINDLE HEIGHT ADJUSTING
(cu_9a-1-1_0.0)
It adjusts the tool to the worktable.
DANGER-WARNING:
the tool adjusting must be carried out with machine off.
9A.1.1.1 SPINDLE HEIGHT ADJUSTING
(cu_9a-1-1-1_0.0)
- Loosen the knob (B fig. 9.1-1-1).
- The spindle height adjusting occurs by means of handwheel (A fig. 9.1-1-1).
- After any adjusting tighten knob (B fig. 9.1-1-1).
DANGER-WARNING:
to take up slack you have to reach the right height always with motion upwards.
FORBIDDEN:
it is forbidden to use the machine, to perform operations that do not require the use of the toupie
shaft, without having first lowered the toupie shaft completely below the worktop.
DANGER-WARNING:
with interchangeable toupie shaft
, in order to lower the toupie shaft itself completely below
the worktop, it is NECESSARY to remove the spacer rings and the screw that blocks them (see Par.
4.3.76.1).
