10.3.1.3 SURFACING AND STRAIGHTENING PIECES THICKER
THAN 75 MM
(fs_10-3-1-3_0.0)
and bridge-type protection
The bridge of the guard shall be lower on the tables and horizontally adjusted to the piece.
1 - Rest the bridge onto the table by means of the knob (B fig. 10.3-1-3) and expose the shaft as it is enough to
let the piece to be machined pass by pulling the bridge away (A fig. 10.3-1-3), after releasing the knob (C fig.
10.3-1-3) (lock the bridge again, then).
2 - Press the guard so that it rests on the outfeed table (1 fig. 10.3-1-3).
Move the piece along the fence with regular motion by keeping the hands flat on the piece (2 fig. 10.3-1-3).
