7 - SUPPORTING FRAME AND FENCE FOR PARALLEL CUTS: USE AND
ADJUSTMENT
THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN Cap. 7 Pag. 25/26
7.24.6.1 EXAMPLE FOR POSITIONING THE RULE FOR OBLIQUE
CUTS
(si_7-24-6-1_0.0)
Cutting position : the panel (W) is pushed by the rule (A)
Cutting position
: the panel (W) is against the rule (A)
