SCM CU 300C - Scorer Spindle

20 - MAINTENANCE
EN
Pag. 32/44 - Cap. 20 THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
20.23.2 SCORER SPINDLE
(ev_20-23-2_0.0)
NOTE-INFORMATION:
the correct engraver belt tension is assured by the spring (G fig. 20.23-2) and it does not require
any adjustment.
Fig. 20.23-2
