SCM CU 300C - Adjustment to Pass from Thicknessing to Surface Planing

9 - THICKNESSING USE AND ADJUSTING
EN
Pag. 4/12 - Cap. 9 THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
9.2 ADJUSTMENT TO PASS FROM THICKNESSING TO
SURFACE PLANING
(fs_9-2_0.0)
NOTE-INFORMATION:
SURFACING TABLES
This operation is carried out for straightening a wood piece and for trimming the long side of a
panel. In this way you get a reference plan for the next working steps. After straightening a ledge
side surface side at 90° in order to carry out the thicknessing: in this way it is possible to obtain a
finished piece planned on all 4 sides.
9.2.1 MACHINE WITH MANUAL TABLE LIFTING
(fs_9-2-1_0.0)
When the thicknessing is finished, to use the surfacing unit:
1) Stop planer motor.
2) Wait few seconds for the complete cutterblock stop.
CAUTION:
before lowering the planing tables, remember to open the chip conveyor guard (F fig. 9.2-1) and
lower the thicknessing table to the red notch (M fig. 9.2-1) so as not to damage any element and
return the lever (L fig. 9.2-1) to the “0” position (deactivation of the feeding rollers).
3) Disengage the block (N fig. 9.2-1) and close the tables.
Lower the surfacing tables (C, D fig. 9.2-1). Turn and push the lever (T fig. 9.2-1) to lock table (C fig.
9.2-1). Turn and push the lever (R fig. 9.2-1) to lock table (D fig. 9.2-1).
