SCM CU 300C - Machining of Narrow Work-Pieces

10 - USE AND ADJUSTMENT OF PLANER SPINDLE GUARD AND SAFE WORKING
EN
Pag. 18/20 - Cap. 10 THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
10.3.1.10 MACHINING OF NARROW WORK-PIECES
(fs_10-3-1-10_0.0)
To machine thin pieces use an auxiliary guide (A) (not supplied by the SCM ).
NOTE-INFORMATION:
this device serves for making the surfacing of thin workpieces easier.
DANGER-WARNING:
to make the auxiliary guide (A) use wood that has NO defects (curvatures, splits, knots, metal
parts).
- Use a strip (A) with a section P (55 mm) x H (22 mm) and length L = (G+T+T), of the same length (G) as the
main guide (F) increased by the thickness (T) of the closure caps (if present).
- Construct two interfaces (S) and secure them to the strip (A) with self-tapping screws (B).
- Then secure the auxiliary guide (A), with the interfaces (S), to the main guide (F) with the screws (V).
