EN
1 - GENERAL INFORMATION
THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN Cap. 1 Pag. 5/24
1.2 MACHINE IDENTIFICATION
(gg-1-2_0.0)
Machine data are punched on the metallic plate applied to the side of the machine frame.
Designation Abbreviated, conventional description of the machine
designation and its function
Marca Merchandise mark
Anno Production year
N° Serie Serial number
kg Weight (kg)
Tipo Machine type
Modello Machine model
Un V Rated voltage (volt)
~ Phases number (alternate current)
In A Rated current (ampere)
F Hz Frequency (hertz)
Icc. kA Short circuit breaking capacity of the protective device
(kA)
w.d. Wiring diagram number
Comp. Machine configurations
Ref. Internal references
