10 - USE AND ADJUSTMENT OF PLANER SPINDLE GUARD AND SAFE WORKING
THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN Cap. 10 Pag. 17/20
10.3.1.9 STRAIGHTENING WORKPIECES OF SMALL SECTION
(fs_10-3-1-9_0.0)
and bridge-type protection
NOTE-INFORMATION:
adjust the bridge guard as described in the previous sections.
Press the workpiece with the hands (clenched fist) against the rule and the table (fig.10.3-1-9)and push it forwards.
The guard is adjusted in horizontal direction against the fence and rests on the workpiece.
Fig. 10.3-1-9
