SCM CU 300C - Surfacing Workpieces with Small Section

10 - USE AND ADJUSTMENT OF PLANER SPINDLE GUARD AND SAFE WORKING
EN
Pag. 16/20 - Cap. 10 THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
10.3.1.8 SURFACING WORKPIECES WITH SMALL SECTION
(fs_10-3-1-8_0.0)
and bridge-type protection
NOTE-INFORMATION:
adjust the bridge guard as described in the previous sections.
Push the workpiece forwards with spread hands (fig.10.3-1-8), like in the case of workpieces with thickness lower
than 75 mm (see par.10.3.1.1).
Fig. 10.3-1-8
