SCM CU 300C - 50 Pressure Unit for Profiling

9a - OPERATIONS AND ADJUSTMENTS OF SPINDLE
EN
Pag. 36/45 - Cap. 9a THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
9A.50 PRESSURE UNIT FOR PROFILING
(cu_9a-50_0.0)
Components (fig. 9.50):
1) - Horizontal pressure shoe
2) - Vertical pressure shoe
3) - Support
4) - Knobs for presser adjusting
5) - Knobs for presser adjusting
6) - Knobs for presser adjusting
7) - Pusher
4) - Knobs for presser adjusting
5) - Knobs for presser adjusting
6) - Knobs for presser adjusting
DANGER-WARNING:
the vertical and horizontal pressure shoes , fastened to the support, are an efficient protection for
the operator's hands and against the eventual ejection of splits or tool parts.
DANGER-WARNING:
all adjustments must be carried out with the shaft stopped.
