SCM CU 300C - 38.4 Hood-Fence Unit Adjusting for Working at the Front End

9a - OPERATIONS AND ADJUSTMENTS OF SPINDLE
EN
Pag. 32/45 - Cap. 9a THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
9A.38.4 HOOD-FENCE UNIT ADJUSTING FOR WORKING AT THE
FRONT END
(9a.38.4)
FORBIDDEN:
for this type of machining it is forbidden to perform through routing.
NOTE-INFORMATION:
this working type requires the interchangeable moulding spindle
with collet for fitting cutters
with cylindrical shank.
For this working type set the hood-fence unit to POSITION 2 , see Par. 4.3.73.1
Simultaneous adjustment of the guides A and B (fig. 9.38-4).
- Adjust fence (A fig. 9.38-4) by means of knob (E fig. 9.38-4) after loosening knob (C fig. 9.38-4).
- Adjust fence (B fig. 9.38-4) by means of knob (E fig. 9.38-4) after loosening knob (G fig.9.38-4).
- The fence halves (A and B fig. 9.38-4) must be as near the tool as possible (about 2-3 mm). To make this
adjustment loosen handles (D fig. 9.38-4) behind the fence halves.
NOTE-INFORMATION:
for this operation the fence halves shall be aligned with one another.
Read the deviation between the two tables on index (H fig. 9.38-4). When the index is positioned on
"0", the fences are aligned.
- When the adjustment has been carried out, tighten the knobs C and G (fig. 9.38-4).
- Before starting the working adjust guards (Q - R - S fig. 9.38-4) in order to protect the operator
against eventual ejection of splints or tool parts.
