EN
3 - TECHNICAL SPECIFICATIONS
THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN Cap. 3 Pag. 7/22
SPECIFICATIONS - Saw blade "DADO SET" ( )
Max. diameter – saw blade “DADO SET” (5/8”) x (8”) Øi 15.9 x 203.2 mm
Maximum thickness for blade unit (3/4”) 19 mm
Maximum projection at 90° 31 mm
Saw blade maximum diameter Øi 15.9 x 315 mm
Saw blade minimum diameter Øi 15.9 x 250 mm
Maximum projection at 90° With 315 mm saw blade 80 mm
Maximum projection at 45° With 315 mm saw blade 65 mm
Maximum projection at 90° With 300 mm saw blade 73 mm
Maximum projection at 45° With 300 mm saw blade 60 mm
Maximum projection at 90° With 250 mm saw blade 48 mm
Maximum projection at 45° With 250 mm saw blade 42,5 mm
