3 - TECHNICAL SPECIFICATIONS
EN
Pag. 8/22 - Cap. 3 THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
MOULDER
GENERAL SPECIFICATIONS
Worktable size: 1115 x 335 mm
Worktable height from the floor: 860 mm
Working spindle height: Ø 30 - 35 - 35 100 mm
Working spindle height: Ø 40 -50 100 mm
Max. tool diameter for rebating (with a perpendicular spindle) Ø 210 mm
with Ø 30 mm spindle 150 mm
with Ø 32 mm spindle 150 mm
with Ø 35 mm spindle 150 mm
with Ø 40 mm spindle 180 mm
Max. tool diameter: moulding hood
with Ø 50 mm spindle 180 mm
Max. tool diameter: tenoning hood Ø 275
275
mm
Max. diameter of the tool disappearing under the table: Ø 180 x h 50 mm
Vertical spindle adjusting: ~ 120 mm
50 Hz 3500 – 7000 - 10000 r.p.m.
Spindle rotation speed
60 Hz 4200 - 8400 - 12000 r.p.m.
Time required to stop the spindle: less than 10 seconds
Motors:
50 Hz 5,0 kW
Main motor power:
60 Hz 6,0 kW
Technical details: see data plate on the motor
Duty cycle: S6 - 40%
Conditions of service: see Par. 1.10
Basic machine weight: see plate of machine identification
Working voltage and frequency: see plate of machine identification
DANGER-WARNING:
the table lists the tool mass allowed based on its speed and diameter.
3500 ( r.p.m. ) (50 Hz) – 4200 ( r.p.m. ) (60 Hz)
Diameter ( mm ) Weight ( Kg )
275 4
