3 - TECHNICAL SPECIFICATIONS
THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN Cap. 3 Pag. 9/22
SURFACE PLANING AND THICKNESSING MACHINE
GENERAL TECHNICAL DATA
CU 300C 1510
Planer table total length
CU 410C 1810
mm
CU 300C 300
Useful working length (Planer - Thicknesser)
CU 410C 410
mm
Max. depth of cut in one stroke (Thicknesser) 4 mm
Max. depth of cut in one stroke (Planer) 3 mm
Min. width of the piece to be machined (Thicknesser) 10 mm
Cutterblock diameter 72 mm
CU 300C 30x3x300
Knives
CU 410C 30x3x410
N° 3
Cutterblock speed (50 Hz - 60 Hz) 5200 rpm
Time required to stop the cutterblock less than 10 sec.
CU 300C 1470x150
Fence dimensions
CU 410C 1650x150
mm
Motors:
50 Hz 5,0 kW
Motor power
60 Hz 6,0 kW
Technical details: see data plate on the motor
Duty cycle: S6 - 40%
Conditions of service: see Par. 1.10
Planer guide tilt from 90° to 45°
Feed speed to thicknesser 7 m/min
Weight without mortiser: see identification plate on the machine
Helicoidal planer with tips
TIP-TOOL ( CU 300C ) 15x15x2,5 48
TIP-TOOL ( CU 410C ) 15x15x2,5 66
SUCTION SPECIFICATIONS
Saw suction mouth diameter Ø 120 mm
Saw guard suction mouth diameter Ø 60 mm
Surfacing planer hood suction mouth diameter Ø 120 mm
Spindle hood suction mouth diameter Ø 120 mm
Tenoning hood suction mouth diameter
Ø 120 mm
Thickness hood suction mouth diameter Ø 120 mm
Mortiser suction mouth diameter
Ø 120 mm
Suction air speed: chips dry (chips wet) 20 (28) m/sec
Suction air consumption [Ø 120 + Ø 60] 1018 (1425) m³/h
Suction air consumption [Ø 120 + Ø 120] 1628 (2280) m³/h
Suction air consumption [Ø 120]
814 (1140) m³/h
