5 - CONTROLS
EN
Pag. 10/14 - Cap. 5 THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
Machine Start procedure
- (U.S.A. and CANADA) Main switch (1 fig. 5.5) is turned to I (ON).
- Move the selector switch (C fig. 5.5) in the chosen working position.
- Set the selector of the magnetothermal switch (B fig. 5.5) to position "I".
- Move in the relevant working site:
With reverse rotation for moulder
- Move the selector switch (C fig. 5.5) in the chosen working position.
- Set the selector of the magnetothermal switch (B fig. 5.5) to position "I".
- Press the (M fig. 5.5) button.
- Move in the relevant working site:
= Surfacing planer.......................................... = Thicknessing planer
= Drilling .................................................. = Parallel cutting
= Moulder machining ..................................... = Slide machining
Machine Stop procedure
- Set the selector of the magnetothermal switch (B fig. 5.5) to position "0".
- Move the selector switch (C fig. 5.5) to position "0".
With reverse rotation for moulder
- Press the (M fig. 5.5) button.
- Set the selector of the magnetothermal switch (B fig. 5.5) to position "0".
- Move the selector switch (C fig. 5.5) to position "0".
