9a - OPERATIONS AND ADJUSTMENTS OF SPINDLE
EN
Pag. 26/45 - Cap. 9a THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
- After loosening knobs (G, C fig. 9.33-4A) move the entire hood- fence unit to the most suitable position for
the depth of cut required, then tighten the knobs.
- The fence halves (A and B fig. 9.33-4A) must be as near the tool as possible (about 2-3 mm). To make this
adjustment loosen handles (D fig. 9.33-4A) behind the fence halves.
For further micrometric adjustment of the depth of cut set the fence half (A fig. 9.33-4A) as follows:
- slacken the knob (C fig. 9.33-4A).
- Turn knob (E fig. 9.33-4A) to find the correct position: indicator (H fig. 9.v) indicates the adjusting measure.
- When the adjustment has been carried out, tighten the knob (C fig. 9.33-4A).
For micrometric adjustment of fence half (B fig. 9.33-4A):
- slacken the knob (G fig. 9.33-4A).
- Turn knob (E fig. 9.33-4A) and with a bar check the alignment of the fence half with the tool.
- When the adjustment has been carried out, tighten the knob (G fig. 9.33-4A).
DANGER-WARNING:
the two fences must be adjusted so the workpiece is stable at both infeed and outfeed.
NOTE-INFORMATION:
Read the deviation between the two tables on index (H fig. 9.33-4A). When the index is positioned
on "0", the fences are aligned.
