20 - MAINTENANCE
EN
Pag. 16/44 - Cap. 20 THIS MANUAL IS PROPERTY OF SCM INDUSTRIA S.P.A - ANY TOTAL OR PARTIAL REPRODUCTION IS STRICTLY FORBIDDEN
SURFACE PLANING AND THICKNESSING MACHINE
Weekly lubricate with grease:
Manufacturer Lubricant name
AGIP GR MU EP1
ARAL ARALUB HL1
BP GREASE LTX1
SHELL SUPER GREASE EP1
MOBIL MOBILPLEX 46
KLÜBER CENTOPLEX 1
ESSO BEACON EP0
1) worm (V fig. 20.3A) for lifting the mortiser
.
2) Thicknessing table - Screw (S fig. 20.3A) for height adjusting.
3) Transmission chain (A fig. 20.3A) of the motion to the feed rollers.
Lubricate with oil here indicated:
Manufacturer Lubricant name
AGIP EXIDIA 220
ARAL DEGANIT B 220
BP ENERGOL GHL 220
SHELL TONNA OIL T220
MOBIL VACTRA OIL N° 4
KLÜBER LAMORA SUPER POLADD 220
ESSO FEBIS K 220
1) sliding rod (D fig. 20.3A) on planer guide.
2) Sliding rods (P fig. 20.3A) of mortiser table
.
3) Guides (E fig. 20.3A) for sliding mortiser
.
NOTE-INFORMATION:
- as all bearings are sealed and lubrificated-for life, they do not require any maintenance;
- when you have to replace these bearings directly apply to SCM Ufficio Ricambi;
- bearings of other makes with corresponding names are NOT suitable.
NOTE-INFORMATION:
protect all belts and pulleys to avoid contamination with oil.
