Nur für den internen Gebrauch System Programming Codes (Expert Mode Codes)
Accessing system administration
16 18 1 Select call destination list and destination index (1 – 4).
Call destination lists:
● up to and including V1.2 = 70
● V3.0 or later =
– 376 for HiPath 3550, HiPath 3500
– 70 for all other systems
Select destination (1 – 4), possible entries:
● targeted call number of a station or a group
● * = identical to called station
● #9 = system search of all stations except for the executive exten-
sions
● #201 – #260 = uniform call distribution group 01 to group 60
● #301 – #316 = announcement device 01 to 16
● an external destination, in other words call numbers in satellites and
in the central office
16 18 2 Internal calls; select station/group:
● up to and including V1.2 = 70
● V3.0 or later =
– 1 – 376 for HiPath 3550, HiPath 3500
– 1 – 70 for all other systems
16 18 3 External calls, day; select station/group:
● up to and including V1.2 = 1 – 70
● V3.0 or later =
– 1 – 376 for HiPath 3550, HiPath 3500
– 1 – 70 for all other systems
16 18 4 External calls, night; select station/group:
● up to and including V1.2 = 1 – 70
● V3.0 or later =
– 1 – 376 for HiPath 3550, HiPath 3500
– 1 – 70 for all other systems
16 18 5 Number of rings (1 to 15) for station/group
16 18 6 Night bell, location for station/group
16 18 7 Night bell, mode:
1 = Immediate connect, 2 = After timeout
16 18 8 Call forwarding (CF) on busy, 0 = Do not forward call, 1 = Forward call
16 19 Ring cadence: 0 = Ring type 1, 1 = Ring type 2, 2 = Ring type 3
16 20 DTMF DID: 0 = denied, 1 = allowed
16 21 Ringback protection (Brazil): 0 = off, 1 = on
Table A-3 Expert Mode Codes
Code Function
