System Programming Codes (Expert Mode Codes) Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

A-16 HiPath 3000/5000 V9, Service documentation

pcodes.fm

Accessing system administration

20 5 2 15 CBC pool:

11 = AT&TSDN-GSDN

12 = AT&TSDDN

13 = MCI-VN-VS

14 = SPRINT-VPN

15 = WICN-PV

16 = MEG800-TFM

17 = MCI 800

18 = ULTRA-800

19 = WICN-INWATS

20 = MEG

21 = MCI-PRISIM-WATS

22 = SPR-ULTRA-WATS

23 = WICN-OUTWATS

24 = ACCU-SDS

25 = LDS-WC-TSAA

26 = INTER-800

27 = MULTIQUEST

28 = MCI-900

29 = SDS56

30 = SDS64C

31 = SDS64R

32 = DMS100-PV

33 = DMS100-INWATS

34 = DMS100-OUTWATS

35 = DMS100-FX

36 = 5ESS-INWATS

37 = WATS-MSB

38 = DMS100-TIE

39 = NI2-INWATS

40 = NI2-OUTWATS

41 = NI2-FX

42 = NI2-TIE

43 = NI2-HOTEL

44 = NI2-SCOCS

20 5 2 16 CBC access code

20 5 3 S0 bus MSN, select slot/port

20 5 4 QSig: S0 parameter

20 6 QSIG parameter

Table A-3 Expert Mode Codes
