Nur für den internen Gebrauch System Programming Codes (Expert Mode Codes)
Accessing system administration
24 1 Entrance phone; select door, max. 6 digits, door 1-4
24 2 Destination; select door, max. 6 digits, door 1-4
24 3 Door opener; select door: 0 = not available, 1 = available, 2 = available
with DTMF, doors 1-4
24 4 Call forwarding, door, external; select door: 0 = do not run, 1 = run
24 5 Door opener, DTMF, select station: 0 = denied, 1 = allowed
25 Announcement/Music
25 1 Announcement devices
25 1 1 In system (select announcement device 1 ... 16)
25 1 2 Via server (select announcement device 1 ... 16)
25 2 Type of ann., select ann. device: 1 = Ann. type, 2 = Music on hold, 3 =
Internal music
25 3 Announcement prior to answer; select slot and trunk
25 4 External MOH
(Only enter analog line module stations.)
26 Relays
26 1 Type; select relay 1 to 4 and assign function:
11 = Manual on and off
12 = Off after timeout
13 = Door opener
14 = Speaker amplifier (starting contact for amplifier)
15 = Busy display
16 = Music on hold
17 = Call charge pulse
18 = Second bell
19 = Station active
20 = Announcement
26 2 Switching time
Select relay 1 through 4 and enter up to 3 digits (0 to 255)
26 3 Assigned station
Select relay 1 through 4 and enter stations or groups
(up to 5 digits)
26 4 Relay name; select relay 1 to 4, enter a name containing up 16 charac-
ters (alphanumeric)
1
Table A-3 Expert Mode Codes
Code Function
