Nur für den internen Gebrauch System Programming Codes (Expert Mode Codes)

Accessing system administration

29 3 1 Type per option (for review only)

1 = Relays

2 = Call detail recording

3 = Fax/DID

4 = ANI

5 = Announcement (Beyer)

29 3 2 Software version for each option (1 to 16) (for verification purposes only)

29 3 3 Reset options

29 4 Boards

29 4 1 Board type, select slot:

11 = TMS2

12 = TMST1 - digital

13 = TIEL

14 = TMDID

15 = TML8W

16 = TMOM

17 = TMGL8

18 = TLA2

19 = TLA4

20 = TLA8

21 = TS2N

22 = TMGL2

23 = TMGL4

24 = TMQ2

25 = TMQ4

26 = TST1 - digital

27 = STMD

28 = STLS2

29 = STLS4

30 = SLA16

31 = SLMO8

32 = SLMO24

33 = SLMC8 (CMI V1)

34 = 4SLA / SLAD4

35 = 8SLA / SLAD8

XX = DIUT2

Table A-3 Expert Mode Codes
